I occasionally need to allow some external service to interact with code that's running on my laptop. A few recent examples included building a UI in Retool against a local API and allowing webhooks from Resend to hit my dev server. I've used ngrok and localtunnel for this, but I've always wanted my own, self-hosted version.

Popular options for self-hosting a tunnel service include Pangolin and frp. I recently saw rustunnel on HN, and the discussion pointed me to this giant list of other alternatives.

All of these solutions tend to be pretty heavy-weight, because creating dynamic tunnels is actually pretty difficult. You can use wildcard DNS to point *.tunnel.example.com to your service, but getting a wildcard cert from LE requires a DNS-based challenge. This means your DNS must be hosted at some dynamic provider like Cloudflare, and you must give your tunnel service some sort of DNS provider API access and credentials. Pangolin supports provisioning named (non-wildcard) SSL certs at tunnel creation time, but this involves some lag for the tunnel to spin up.

If you're a small-time dev with only an occasional need, you might be happy to just have a static tunnel name, like mytunnel.example.com. A static name also has a security benefit -- with dynamic tunnels, if you release a name that still has webhooks pointed at it, the next person to claim it could receive your traffic. Here's an approach I use, which works well for me because I already run a docker compose stack with an instance of traefik in it.

Simple Tunnel

Here's a step-by-step guide for setting up your simple private tunnel. I'm going to give some TL;DR steps, followed by an explanation of what's happening if you're curious. This setup is meant to run on a machine which has a public IP address and is already configured to send HTTP/s traffic from that IP to a docker compose stack fronted by traefik.

DNS

First, pick a DNS name for your tunnel. Update your DNS provider to point the tunnel name at your traefik instance. We're going to stick with tunnel.example.com for this tutorial.

Docker compose network

We need to make your compose stack's default bridge network have an explicit, not an auto-assigned, IP address. Here's an example config for the top-level networks key, which you can customize:

networks:
  default:
    driver: bridge
    ipam:
      config:
        - subnet: 172.20.1.0/24
          ip_range: 172.20.1.0/24
          gateway: 172.20.1.1
    driver_opts:
      com.docker.network.bridge.name: "tunnelnet"

For the bridge name, you can use whatever descriptive name fits your stack, or you can just omit it. For the subnet, you can pick any available network in a private network address range; I think a /24 should be plenty for most compose stacks. You'll probably need to take your compose stack down and then back up for this change to take effect.

More details about docker networking

To understand this, you need to understand docker's networking model. Most compose stacks run in bridge mode, and we're sticking with that here. In bridge mode, when your stack boots up, docker creates a virtual network bridge and allocates it a private network. Containers in the stack get allocated an address within this network, and traffic between containers is routed via this virtual bridge. If you need outside traffic to get to a container in the stack -- for example, HTTP/s traffic intended for the stack's traefik instance -- then you can configure forwarding using the ports key.

We're going to be telling traefik to forward our tunnel traffic to a port on the virtual bridge. This means we need the bridge to have a specific -- not a randomly assigned -- gateway address.

Note that docker also supports host-based networking, where instead of a virtual bridge your containers just listen on the host's network interfaces. In this case, you don't need this bridge config. But I don't recommend host-based networking, since it allows your compose services to access other, potentially private services running on the machine or in other compose stacks.

Configure Traefik

We need to tell Traefik to send traffic intended for the tunnel name to a specific port on the stack's bridge. This requires setting up an entrypoint and a service; here's an example:

entrypoints:
  https:
    address: ":443"

http:
  routers:
    tunnel:
      rule: "Host(`tunnel.example.com`)"
      service: "tunnel"
      entryPoints: ["https"]
      tls:
        certResolver: le

  services:
    tunnel:
      loadBalancer:
        servers:
          - url: "http://172.20.1.1:8642"

You might need to restart your traefik instance for these changes to take effect.

More details about traefik config

The entrypoint tells traefik to listen on port 443. You probably already have this configured if you're using Traefik for other services. Next, we define a tunnel router, which causes Traefik to provision an SSL cert for that name (this assumes you already have a le certificatesResolvers configured in your Traefik static config). Finally, we tell Traefik to send traffic coming into this service to port 8642 on the stack's bridge interface. You can pick a different port if you don't like 8642 -- just be consistent in the sections below.

Configure SSHD

Your SSH server config is probably located in /etc/ssh. Edit sshd_config to include the line:

GatewayPorts clientspecified

Make sure there are no other GatewayPorts lines ahead of this. You might need to restart SSHD for this to take effect:

# /usr/sbin/sshd -t && systemctl reload ssh

More details about GatewayPorts

We want our SSH remote tunnels to attach directly to the compose stack's bridge. However, by default SSHD only allows reverse tunnels to bind to the host's loopback interface. This change to the config allows us to specify a different address -- in our case, the address of the stack's bridge -- for the remote tunnel to bind to.

Configure Firewall

If your server is like mine, it is running some sort of firewall to restrict which services can be accessed. In our case, we need to allow traefik to access our tunnel port (8642) on the bridge interface. If you're using ufw, run:

# ufw allow in from 172.20.1.0/24 to 172.20.1.1 port 8642 proto tcp comment 'Tunneled traffic for tunnel.example.com'

If you're using iptables or nftables directly, or some other firewall system, you'll need to translate that command.

Activate your tunnel

On your computer running the dev service you're trying to expose, run:

$ ssh -N -R 172.20.1.1:8642:localhost:3000 tunnel.example.com

This command exposes the local service on port 3000 to the internet at tunnel.example.com. Congratulations, your tunnel is now complete! When you're done with it, simply Ctrl-C the ssh command.
